A Navarre consortium develops a health monitoring system for modular wind blades
The Navarre-based companies Nabrawind and Aresse and AIN (Navarre Industry Association) are developing a project to monitor the structural health of the modular blades that the wind energy sector expects to massively implement in the upcoming years. This project is included under the umbrella of Digital Alliances Projects 2022-23 promoted by the Government of Navarra.
The blades are one of the most sensitive parts of a wind turbine and, in fact, are responsible for a relevant percentage of the failures in a wind turbine. These failures lead to undesired shutdowns in wind farms and reduce their productivity while increasing their costs with laborious repair maneuvers.
Consequently, modifying the blade design by introducing a discontinuity zone and off-site assembly is perceived as increasing the risk of breakage. In addition, as this is a technology that has only recently been incorporated into the market, there are insufficient records to demonstrate its reliability. All this makes the application of monitoring systems to this technology essential to ensure its deployment and achieve a robust market introduction.
Thus, the three Navarre-based entities are undertaking this new project, called Healh Monitoring of modular wind turbine blades through the development of digital twins and the integration of advanced sensors.
Specifically, the Navarre consortium will use the modular blade joint developed by Nabrawind, called Nabrajoint®, as a study bank for the development of this project, which will culminate with the creation of the so-called Digital Twin of the blade joint. This is a software capable of hybridizing real data from the wind turbine site, the turbine and the joint itself with simulations that, ultimately, combined with AI systems, will make it possible to establish the real state of the modular blade and, consequently, improve the reliability of the modular blades.
This project has been funded by IRIS, Polo de Innovación de Navarra through #REACTFunds.
In this line, the project that the Navarre entities are developing pursues four strategic objectives that will benefit both the wind power industry and the Navarre industry itself:
- Reduction of the environmental impact and promotion of the circular economy, thanks to the implementation of modular blades and the advantages that this entails in logistical and environmental terms.
- Improvement in the reliability of the modular blades, thanks to the health monitoring system of the blades, which will make up for the lack of operating records of this technology and the perception that they are less safe than traditional blades.
- Extending the life of wind farms. The availability of monitoring systems, such as Health Monitoring, will make it possible to verify the condition of the wind farms and demonstrate that they are in correct operating conditions and, consequently, they will be able to extend their useful life.
- Finally, the project led by these three companies from Navarra will confirm Navarra as a pioneering region in wind energy.
